APC Back-UPS 1200VA, 120V, AVR

Main
Run time for load W information_stroke Min-max: 65-650 W	1min 1s
Max. Capacity Used information_stroke	100 %
Main Input Voltage	120 V AC 1 phase
Output voltage	120 V AC 1 phase
Rated power in W	650 W
Rated power in VA	1200 VA
Input Connection Type	NEMA 5-15P
Output connection type	6 NEMA 5-15R
Cable length	1.52 m
Number of cables	1
Battery type	Lead-acid battery

General
Number of power module free slots	0
Number of power module filled slots	0
Redundant	No
UPS size	WS

Output
Maximum configurable power in W	650 W
Output frequency	50/60 Hz +/- 1 Hz sync to mains
UPS type	Line interactive
Wave type	Stepped approximation to a sinewave
Efficiency	98 % (full load)
Full load runtime	00:01:00 650 W
Graph display	1
Half load runtime	00:06:00 325 W
Maximum configurable power in VA	1200 VA
Transfer time	6 ms typical : 10 ms maximum

Conformance
Product certifications	NOM

Environmental
Ambient air temperature for operation	0…40 °C
Relative humidity	0…95 % non-condensing
Operating altitude	0...3000 m
Ambient air temperature for storage	-15…40 °C
Storage Relative Humidity	0…95 % Non-condensing
Storage altitude	0…3000 m
Acoustic level	40 dBA
IP degree of protection	IP20

Batteries & Runtime
Run Time	View Runtime Graph action_new_window
Efficiency	View Efficiency Graph action_new_window
Number of battery filled slots	0
Number of battery free slots	0
Battery recharge time	8 h
Battery voltage	12 V
Battery capacity	9.0 Ah
Battery life	2…3 year(s)
Replacement battery	APCRBC175 action_new_window
Extended runtime	0

Communications & Management
Control panel	LED Status display with on line : on battery
Alarm	Alarm when on battery : distinctive low battery alarm

Surge Protection and Filtering
Surge energy rate	350 J
